| Engine | Cummins-NT 855 R developing 240 hp @2100 rpm |
| Transmission | AVTEC. Model : CRT-5633 |
| Tare Weight | 22,000 kg |
| Gross Weight | 32,000 kg |
| Axle load | 16,000 kg |
| Wheel dia | 915 mm (new) / 813 (fully worn) |
| Length over head stock | 8540 mm |
| Width over body wall | 3250 mm |
| Floor height | 1325 mm |
| Max. operating speed | 75 kmph |
| Suspension | Coil spring with Shock absorber |
| Brake | Air brake, clasp type |
| Lifting & Swiveling Platform |
Capacity : 500 kg
Lifting Height : 6150 m
Swivel : ±900
|
Available in different Gauges / Speeds / Vehicle Configuration.
Build to order custom machines to suit the client / job site's specific requirement.
